Stretch Blow Moulding Machine Manufacturer

This machine is designed for manufacturing PET bottles and jars with high precision and consistent output. Ideal for water, beverages, cosmetics, household and industrial packaging.

It features hydro-pneumatic operation, efficient heating, and stable moulding performance. Durable design ensures long working life with low maintenance needs.

Supports bottle sizes from 50 ML to 25 LTR

Output capacity up to 700 Bottles Per Hour

Hydro-Pneumatic smooth operation for consistent shaping

Get Quote

Product Details

Technical Specification

Description / Model	HP-1000-2B	HP-2000-2JB	HP-5000-JB	HP-20-CS
Product Size	50 ML – 1000 ML	50 ML – 3000 ML Bottle / Jar	50 ML – 7500 ML	5 LTR – 25 LTR
Product Output	600–700 BPH	450–700 BPH	350–700 BPH	150–240 BPH
Mould Cavity	2 Cavity	2 Cavity	2 Cavity upto 3 LTR / 1 Cavity upto 7.5 LTR	1 Cavity
Neck Size	19–32 MM	19–96 MM	19–120 MM	45–135 MM
Heater Power	10 KW	12 KW	12 KW	32 KW
Clamping Stroke	150 MM	200 MM	250 MM	350 MM
Working Pressure	8 KG / CM²	8 KG / CM²	8 KG / CM²	8 KG / CM²
Blowing Pressure	22–25 KG / CM²	22–25 KG / CM²	22–25 KG / CM²	22–25 KG / CM²
Air Requirement	0.7 M³/MIN	0.8 M³/MIN	0.9 M³/MIN	2 M³/MIN
Operation	Hydro-Pneumatic	Hydro-Pneumatic	Hydro-Pneumatic	Hydro-Pneumatic
Area Required	5 MTR x 5 MTR	5 MTR x 5 MTR	5 MTR x 5 MTR	5 MTR x 5 MTR
Staff Required	2	2	2	2

In today's competitive packaging industry, producing high-quality PET bottles requires advanced machinery that delivers speed, precision, and reliability. Choosing the rightStretch Blow Moulding Machine Manufactureris essential for businesses that want to improve production efficiency, reduce operational costs, and manufacture premium-quality PET bottles.

Suraj Plastic Industries is a trusted Stretch Blow Moulding Machine Manufacturer in India, offering innovative and high-performance PET bottle manufacturing machines for businesses of all sizes. Our machines are designed with advanced technology, energy-efficient systems, and robust engineering to ensure long-lasting performance and maximum productivity.

Whether you manufacture mineral water bottles, soft drink containers, edible oil bottles, pharmaceutical packaging, cosmetic bottles, or industrial containers, Suraj Plastic Industries provides reliable stretch blow moulding solutions tailored to your production needs.

Why Choose Suraj Plastic Industries?

When investing in a PET bottle manufacturing machine, selecting an experienced manufacturer is just as important as choosing the machine itself. At Suraj Plastic Industries, we combine technical expertise, modern manufacturing, and exceptional customer support to deliver machinery that meets international quality standards.

What Makes Us Different?

High-performance PET bottle making machines

Precision engineering for consistent bottle quality

Energy-efficient operation

Heavy-duty machine construction

Low maintenance requirements

Affordable pricing

Custom machine configurations

Reliable after-sales support

Genuine spare parts availability

Fast installation and technical assistance

Our commitment to quality has made us one of the preferredStretch Blow Moulding Machine Manufacturers for businesses across India.

Fully Automatic Stretch Blow Moulding Machine

Designed for high-volume production units requiring continuous manufacturing with minimal manual intervention.

Advantages

High production speed

Reduced labor costs

Automatic bottle production

Higher efficiency

Consistent output quality

Features of Our Stretch Blow Moulding Machines

Every machine manufactured by Suraj Plastic Industries is built for long-term performance and high production efficiency.

Advanced Heating System — Ensures uniform heating of PET preforms for accurate bottle formation.

Precision Blow Moulding Technology — Produces bottles with consistent wall thickness and excellent transparency.

Heavy-Duty Construction — Strong machine body designed for continuous industrial operation.

Energy-Efficient Design — Consumes less electricity while maintaining high productivity.

User-Friendly Control Panel — Easy machine operation with simplified controls.

Fast Production Cycle — Higher output with reduced cycle time.

Low Maintenance — Minimal servicing requirements reduce operational costs.

Reliable Pneumatic System — Ensures stable air pressure throughout the production process.

Technical Advantages

Businesses choose Suraj Plastic Industries because our machines offer several engineering benefits.

High production accuracy

Uniform bottle quality

Strong bottle neck finish

Stable stretching mechanism

Low rejection rate

Smooth bottle surface

Easy mould changing

Consistent heating temperature

Long operational life

High production efficiency

Benefits of Choosing a Trusted Stretch Blow Moulding Machine Manufacturer

Selecting the right manufacturer provides long-term advantages beyond simply purchasing a machine.

Superior Machine Quality — Premium materials ensure durability and long service life.

Better Productivity — Advanced engineering allows higher bottle production with consistent quality.

Lower Operating Costs — Energy-efficient systems reduce electricity consumption.

Customized Machine Solutions — Machines are designed according to bottle capacity, production output, and business requirements.

Expert Technical Support — Professional installation, training, and maintenance assistance ensure smooth operation.

Genuine Spare Parts — Quick availability of original spare parts minimizes production downtime.

Bottle Sizes Our Machines Can Produce

Depending on the mould configuration, our machines can manufacture:

200 ml PET Bottles

250 ml Bottles

500 ml Bottles

1 Litre Bottles

2 Litre Bottles

5 Litre Containers

Wide Mouth Bottles

Custom PET Bottles

This flexibility allows businesses to serve multiple industries with a single machine setup.

Why Businesses Across India Trust Suraj Plastic Industries

Our reputation as a trusted Stretch Blow Moulding Machine Manufacturer is built on years of delivering reliable machinery and exceptional customer service.

Customers choose us because we offer:

Premium quality manufacturing
Competitive pricing
Timely delivery
Customized machine solutions
Expert engineering support
Installation assistance
Operator training
Long-term technical service
Reliable after-sales support

Our goal is not just to supply machinery but to become a long-term manufacturing partner for our clients.

Quality Standards at Suraj Plastic Industries

Quality is at the core of everything we manufacture.

Every Stretch Blow Moulding Machine undergoes rigorous quality checks to ensure:

Precision engineering
Smooth machine operation
Stable production
High bottle accuracy
Reliable safety standards
Excellent finishing
Long machine life

This commitment to quality helps customers achieve consistent production with minimal downtime.

Best Stretch Blow Moulding Machine Manufacturer in India — Suraj Plastic Industries

When you are planning to manufacture PET bottles — whether for water, juice, oil, or cosmetics — the most important decision you will make is choosing the right stretch blow moulding machine manufacturer behind it.

At Suraj Plastic Industries, we have been building stretch blow moulding machines since 1982. That is over 40 years of hands-on experience, 3000+ machines delivered, and a reputation that has been earned — not just claimed.

This page will help you understand everything you need to know before making a decision — from how the machine works to which model suits your production need.

What Is a Stretch Blow Moulding Machine?

A stretch blow moulding machine manufacturer equipment that converts a PET preform into a finished, ready-to-fill plastic bottle. It does this through a precise combination of heat, mechanical stretching, and high-pressure air blowing — all happening inside a mould that gives the bottle its final shape.

The result? A bottle that is lightweight, crystal clear, strong, and perfectly shaped — every single time.

This technology is used to produce billions of plastic bottles every year across India and worldwide — from the 500ml water bottle on your desk to the 2-litre cooking oil container in your kitchen.

How Does a Stretch Blow Moulding Machine Work?

The process is straightforward, but the precision behind it is what makes all the difference:

Step 1 — Preform Loading

A PET preform (a small, thick plastic tube with a finished bottle neck) is loaded into the machine — either manually (semi automatic) or by an automated feeder (fully automatic).

Step 2 — Infrared Heating

The preform passes through a multi-zone infrared heating system. Each zone heats specific parts of the preform to a precise temperature. This is critical — uneven heating leads to uneven wall thickness in the final bottle.

Step 3 — Mould Clamping

The heated preform is transferred into the bottle mould. The mould closes firmly around it.

Step 4 — Stretching

A stretch rod pushes down through the preform, stretching it vertically to the correct length. This is the "stretch" in stretch blow moulding.

Step 5 — Blowing

High-pressure air (22–25 kg/cm²) is blown into the stretched preform, pushing the softened plastic outward into every corner of the mould.

Step 6 — Cooling and Ejection

The mould cools the bottle rapidly, the mould opens, and a perfectly formed bottle is ejected — ready for filling, capping, and labelling.

The entire cycle — from loading to finished bottle — takes just a few seconds.

Types of Stretch Blow Moulding Machines We Manufacture

1. Semi Automatic Stretch Blow Moulding Machine Manufacturer

The operator loads the preform manually. The machine handles heating, stretching, and blowing automatically. Ideal for small to medium scale production with output of 1000–1200 bottles per hour.

Best for: New businesses, small packaged water plants, startups entering the beverage or cosmetic packaging space.

2. Fully Automatic Stretch Blow Moulding Machine Manufacturer

End-to-end automated operation — from preform feeding to bottle ejection. No manual intervention needed in the blowing cycle. Higher output, higher efficiency, designed for large-scale production.

Best for: Established manufacturers with high daily production requirements and larger factory setups.

Specification	HP-1000-2B	HP-2000-2JB	HP-5000-JB	HP-20-CS
Bottle Size	50 ml – 1000 ml	50 ml – 3000 ml	50 ml – 7500 ml	5 Ltr – 25 Ltr
Output (BPH)	600–700	450–700	350–700	150–240
Mould Cavity	2 Cavity	2 Cavity	2 Cavity (up to 3L) / 1 Cavity (up to 7.5L)	1 Cavity
Neck Size	19–32 mm	19–96 mm	19–120 mm	45–135 mm
Heater Power	10 KW	12 KW	12 KW	32 KW
Clamping Stroke	150 mm	200 mm	250 mm	350 mm
Working Pressure	8 kg/cm²	8 kg/cm²	8 kg/cm²	8 kg/cm²
Blowing Pressure	22–25 kg/cm²	22–25 kg/cm²	22–25 kg/cm²	22–25 kg/cm²
Air Requirement	0.7 m³/min	0.8 m³/min	0.9 m³/min	2 m³/min
Operation	Hydro-Pneumatic	Hydro-Pneumatic	Hydro-Pneumatic	Hydro-Pneumatic
Area Required	5 x 5 MTR	5 x 5 MTR	5 x 5 MTR	5 x 5 MTR
Staff Required	2	2	2	2

Not sure which model fits your production plan? Contact our team — we will help you choose without any pressure.

Industries That Use Our Stretch Blow Moulding Machine Manufacturer

Packaged Drinking Water

The biggest application in India. From 200ml cups to 20-litre jars — our machines handle the full range that water plant businesses need.

Carbonated Soft Drinks and Juices

CSD bottles need high strength and accurate neck dimensions to hold carbonation pressure. Our machines produce exactly that — consistently.

Edible Oil and Food Packaging

Food-grade PET bottles with thick, durable walls and clear transparency — exactly what cooking oil and food product brands need.

Cosmetics and Personal Care

Lightweight, attractive bottles for shampoos, conditioners, body lotions, and face care products — with mould flexibility to create unique shapes.

Pharmaceuticals and Health Products

Accurate, clean, and tamper-evident PET containers for syrups, health drinks, and supplement products.

Household and Industrial Products

Detergents, cleaning liquids, pesticides — our machines produce bottles for a wide range of non-food applications as well.

What Makes a Good Stretch Blow Moulding Machine Manufacturer?

Before you buy any machine — from us or anyone else — here are the things you must check:

Heating System Quality — Uniform heating is the foundation of a good bottle. An infrared heating system with multiple independent zones gives you precise control over how the preform is heated — and directly impacts bottle wall thickness consistency.

Blowing Pressure Control — Consistent blowing pressure (22–25 kg/cm²) is essential for producing bottles with uniform shape. Fluctuating pressure leads to deformed bottles and higher rejection rates.

Mould Quality and Changeover Time — High-quality moulds produce bottles with sharper definition and longer life. Fast mould changeover lets you switch between bottle designs without losing too much production time.

After-Sales Support — A machine is not just a one-time purchase. Spare parts availability, technical support response time, and the manufacturer's service network matter just as much as the machine itself.

Energy Efficiency — Infrared heating systems that heat only what is needed — not the entire preform uniformly — save electricity and reduce operating costs over the machine's lifetime.

Why Suraj Plastic Industries?

There are several stretch blow moulding machine manufacturers in delhi. Here is why our customers keep coming back — and why they refer others to us:

40+ Years of Manufacturing Experience — We started in 1982 — when PET bottle manufacturing in India was in its early days. We have seen the technology evolve, and we have evolved with it. That experience is built into every machine we make.

ISO 9001:2015 Certified — Our manufacturing processes are certified. That means every machine leaving our factory has been built and inspected to a verified quality standard — not just our word for it.

NSIC Recognized Manufacturer — We are officially recognized by the National Small Industries Corporation — a mark of credibility and trust for businesses purchasing industrial equipment.

3000+ Machines Delivered Across India — From small packaged water startups in Tier 3 cities to established beverage manufacturers — our machines are running across every region of the country.

New Delhi Based — Pan-India Reach — Being located in New Delhi gives us strong logistics access to all Indian states. Installation, commissioning, and service visits can be arranged quickly.

Complete Installation and Commissioning Support

We do not just deliver the machine. Our team installs it at your site, tests it, and ensures it is running at full performance before we leave.

Operator Training Included

Your team will be trained hands-on — so your operators know exactly how to run the machine, handle routine maintenance, and identify small issues before they become big ones.

Reliable After-Sales Service

Spare parts are available. Technical support is accessible. We have been in this business long enough to know that after-sales service is where trust is truly built or broken.

Stretch Blow Moulding Machine — Buying Guide

If you are evaluating stretch blow moulding machine manufacturer in delhi for your business, here is a simple checklist to help you make the right decision:

Define your production volume — How many bottles per day do you need? This determines whether semi automatic or fully automatic suits you.

Know your bottle sizes — What capacities will you produce? 200ml, 500ml, 1L, 2L? This determines which model and mould configuration you need.

Check your available space — Most of our machines need only a 5 x 5 metre area, but make sure your factory layout is planned before ordering.

Confirm utility availability — You will need a compressor for high-pressure air and stable power supply. Plan these before installation.

Ask about moulds — Confirm whether the moulds for your specific bottle design are included or need to be ordered separately.

Check service support in your area — Ask the manufacturer about their service reach in your state or city.

Frequently Asked Questions

We offer advanced technology, durable machines, customized solutions, competitive pricing, and dependable after-sales support to help businesses achieve efficient PET bottle production.

These machines are widely used in the mineral water, beverage, pharmaceutical, food, cosmetic, dairy, chemical, and industrial packaging sectors.

Yes. Our machines support a wide range of bottle capacities and custom mould designs.

Yes. Suraj Plastic Industries offers installation assistance, operator training, maintenance support, and genuine spare parts.

Absolutely. Our machines are designed with energy-saving technology to reduce operating costs while maintaining high production efficiency.

Partner with Suraj Plastic Industries for Reliable PET Bottle Manufacturing Solutions

If you are searching for a dependable Stretch Blow Moulding Machine Manufacturer, Suraj Plastic Industries is your trusted partner for advanced PET bottle manufacturing technology. Our machines are engineered to deliver exceptional performance, precision, and durability while helping businesses increase productivity and reduce manufacturing costs.

With a strong focus on innovation, quality, and customer satisfaction, we provide complete PET bottle making solutions backed by expert technical support and reliable after-sales service. Whether you are starting a new production unit or expanding an existing facility, Suraj Plastic Industries has the expertise and machinery to help your business grow with confidence.

Final Thought

Whether you are starting a new PET bottle business or upgrading your existing production setup — we are ready to help you find the right stretch blow moulding machine manufacturer for your exact needs.

Talk to our team. Tell us your production requirement, bottle sizes, and budget — and we will give you an honest recommendation.
